移动生物侦检仪

供应商凌天装备集团

型号RAMP

产品商标

联系电话010-51652021 13370188210

促销价

更新时间2015-10-14 14:20:00

浏览次数2907

推荐产品

RAPM移动式生物快速侦检仪

产品型号:RAMP

产地:加拿大


RAMP生物快速检测系统是一款层析免疫检定装置,能够快速提供有关生物威胁的诊断结果。RAMP可以用于测定几乎所有的免疫活性物质。该系统标准配置包括用于探测炭疽杆菌、天花病毒、蓖麻毒素及肉毒毒素的检测试剂盒。

受美国国土安全部(DHS)委托,经美国官方分析化学师协会(AOAC)、疾病预防控制中心(CDC)及军方等十二家独立实验室测试,在众多产品中, RAMP生物快速检测系统是通过标准的炭疽现场检测的系统。

应用领域

应急突发事件现场

重要活动、群体集会场所

车载、舰载使用

区域监测系统

卫生疾控中心

机场、海关

技术参数

产 地:加拿大

工作原理:干式免疫荧光检测法

检测功能:炭疽、蓖麻毒素、肉毒素、天花毒素(痘病毒)

检测精度:炭疽杆菌4ng(4000个孢子);肉毒素5ng;蓖麻毒素10ng;天花毒素3.6ng

供电方式:可外接220V交流电;内置充电电池可独立检测100

数据输出:RS-232

尺 寸:() x () x ()

重 量:

工作温度:-10 - +

防护等级:ZEC 6医学电磁兼容设备,CAN/CSA 601.1FCC CFR47 Part 15/B

RAMP® READER HIGHLIGHTS

A true point of care testing solution

A fully portable (battery and/or AC power), lightweight reader; runs up to 100 tests on one charge

Self-diagnostic and internal quality control checks

No calibration or maintenance required

Menu allows for RAMP® Reader customization

Multiple access levels for enhanced security including operator lockout

Internal electronic quality control (IQC) and external liquid QC (LQC) available

Stores up to 500 sample, 65 IQC results and 35 LQC results

Stores lot information – up to and including 50 lots

Data can be exported to a computer or LIS

Barcode wand and printer accessories also available for the RAMP® Reader

RAMP® READER OPERATION PRINCIPLES

The RAMP® Reader uses proprietary software to read pre-programmed lot cards

The lot card is inserted into the RAMP® Reader prior to running a new test lot and enables the RAMP® Reader to automatically determine the test that is being run and calibrates the RAMP® Reader on a lot-specific basis. No user calibration required!

The RAMP® Reader rejects used or expired cartridges or insertion of a new cartridge without previous lot card entry

The test cartridge is prepared, as per the Instructions for Use, and inserted into the RAMP® Reader

If the RAMP® Reader detects any errors, a clear error message will display on-screen instead of reporting a wrong result

The RAMP® Reader calculates the RAMP® Ratio to correct for sources of variability; time to result is ~15 minutes


产品特点

快速、灵敏、精准、便携、大容量存储、现场使用

高特异性:不相关毒素,结果均为阴性

样本多样:粉末、液体、印痕均可

内部质控:独有内部质量控制带,准确消除系统误差

批间质控:高精度批号卡,消除批次间差异

操作简易:简单培训即可独立操作

结果输出:可存储500条检测结果,液晶屏显示,

可选打印机打印,亦可连接实验室信息系统(LIS)
